2025/03/06Fuzhou, China — March 2025 — Tucsen Photonics today announced the launch of the Gemini 8K TDI, its next-generation high-speed TDI-sCMOS camera designed to meet the rigorous performance and reliability demands of advanced semiconductor inspection and precision scientific imaging.
Next-Generation TDI Performance for Advanced Industrial Inspection
The Gemini 8K TDI builds on Tucsen’s proven TDI-sCMOS technology platform, integrating a 100G CoF high-speed interface and a 1 MHz @ 8K line-rate architecture to achieve next-level data throughput and imaging efficiency.
Combined with thermoelectric sensor cooling for stable 0 °C operation, the system delivers superior signal-to-noise ratio (SNR), uniformity, and long-term reliability — providing a high-throughput, low-noise imaging solution for demanding industrial inspection environments.
1 MHz @ 8K: Double the Data Throughput
Delivering twice the data throughput of its predecessor, the Gemini 8K TDI achieves a 1 MHz line rate at full 8K resolution in 8-bit and 10-bit modes, and 500 kHz in 12-bit mode for higher dynamic range imaging.
This leap in performance enables faster, more detailed image capture — significantly accelerating industrial inspection workflows.
Broad-Spectrum and UV-Enhanced Sensitivity
For nanoscale manufacturing and defect detection, UV imaging has become indispensable.
The Gemini 8K TDI features a broad spectral response from 180 nm to 1100 nm, achieving a peak quantum efficiency (QE) of 93.4% in the visible range, 63.9% QE at 266 nm, and 58% at 355 nm.
These optimizations deliver superior defect detection efficiency, shorter exposure times, and higher SNR imaging across a wide range of materials.
High-Bandwidth 100G CoF Interface
As one of the first TDI cameras to feature a 100G CoF (Chip-on-Flex) interface, the Gemini 8K TDI achieves 100 Gbps data throughput via a single high-speed interconnect.
This architecture reduces PCB routing complexity and minimizes connector-induced signal loss, enhancing overall system stability, signal integrity, and integration flexibility for inspection systems requiring ultra-high-speed data transmission.
0°C Stable Cooling for Precision Uniformity
In precision inspection, even grayscale variations of just 1–2 DN can impact measurement accuracy.
The Gemini 8K TDI employs active thermoelectric cooling to maintain a stable 0°C sensor temperature, ensuring low-noise performance and a uniform imaging background.
This enables consistent quantitative data acquisition across extended inspection runs — a critical advantage in semiconductor and scientific imaging workflows.
The Tucsen Gemini 8K TDI is now available. For full technical specifications and application details, please visit www.tucsen.com
About Tucsen Photonics
Tucsen Photonics Co., Ltd. is a leading developer and manufacturer of high-performance imaging solutions for scientific, industrial, and life science applications. With operations in China, Singapore, the United Kingdom, the United States, and Europe, Tucsen delivers innovative and reliable imaging technologies that empower researchers and engineers worldwide to see beyond the limits of vision.
