MIchrome 16

16MP USB3.0 CMOS Camera with Live Stitching and Live EDF.

  • 7.77mm Diagonal FOV
  • 4608 x 3456 Resolution
  • 1.34μm x 1.34μm Pixel Size
  • 12fps@16MP
  • USB3.0
Pricing and Options
  • products_banner
  • products_banner
  • products_banner
  • products_banner

Overview

MIchrome 16 is a 16-megapixel color camera that can run four cameras at the same time on the SDK. It is suitable for open-field imaging applications with true colors and richer imaging details, which can help users capture clear and high-quality images in bright-field.

  • Live Stitching

    It can generate large-sized mosaic images in a few seconds while moving the stage, which is light, smooth and worry-free!

    Live  Stitching
  • Live EDF

    Turning the focus ring to capture different depth of field points while generating clear depth of field images, fast, accurate and efficient.

    Live  EDF
  • Wide Range Color Temperature Adjustment

    The MIchrome 16 has an integrated 1800-10000K color temperature adjustment,significantly improves the white balance, delivering incredible color fidelity in the original image, eliminating the need for any post processing.

    Wide Range Color Temperature Adjustment

Specification >

  • Model: MIchrome 16
  • Sensor Type: CMOS
  • Sensor Model: SONY IMX206CQC
  • Color/Mono: Color
  • Array Diagonal: 7.77mm
  • Resolution: 16MP, 4608(H)x3456(V)
  • Pixel size: 1.34μmx1.34μm
  • Effective area: 6.2mmx4.6mm
  • Shutter Mode: Rolling
  • Frame Rate: 12fps@4608x3456
  • Exposure Time: 22μs-26s
  • Binning: 2x2, 3x3, 4x4
  • Color Temperature: 2000-15000K
  • PC Software: Mosaic V2
  • Picture Format: TIFF/JPG/PNG/DICOM
  • Multiple Cameras: Supports 4 Cameras Simultaneously in SDK
  • SDK: C/C++, C#, Directshow/Twain
  • Optical Interface: Standard C Mount
  • Bit Depth: 16/8bit
  • Power: 3W
  • Dimensions: 68mmx68mmx46mm
  • Data Interface: USB3.0
  • Operating Environment: Temperature:-10~45℃; Humidity:10%~85%
  • Camera Weight: 327g
  • Operating System: Windows 7/10 (32 Bit/64 Bit)/Mac
  • PC Configuration: CPU: Intel Core i5 or better(Quad or more Core), RAM: 8G or more,
+ View all

Applications >

Download >

  • MIchrome Serices Brochure

    MIchrome Serices Brochure

    download zhuanfa
  • MIchrome Serices Dimension

    MIchrome Serices Dimension

    download zhuanfa
  • Software-Mosaic V2.4.0 (Windows)

    Software-Mosaic V2.4.0 (Windows)

    download zhuanfa
  • Software-Mosaic V2.3.1 (Mac)

    Software-Mosaic V2.3.1 (Mac)

    download zhuanfa
  • Plugin-Directshow and Twain

    Plugin-Directshow and Twain

    download zhuanfa
  • Driver-TUCam Camera Driver V1.5.0.1

    Driver-TUCam Camera Driver V1.5.0.1

    download zhuanfa
